Semi Automatic Flatbed Die Cutter 1040×720mm 17mm Gripper Margin 7500s/H
| Place of Origin | CHINA |
|---|---|
| Brand Name | FINTEECH |
| Certification | CE |
| Model Number | FM-HK1050CE |
| Minimum Order Quantity | 1set |
| Packaging Details | wooden case |
| Delivery Time | 20-30 days |
| Payment Terms | TT/LC |
| Supply Ability | 10 sets per day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Automatic Grade | Semi-Automatic | Driven Type | Electric |
|---|---|---|---|
| Material | Steel | Power Source | Electric |
| Condition | New | Type | Die Cutting Machine |
| Port | TIANJIN,CHINA | Packaging Type | Bags, Cartons, Case |
| Highlight | Semi Automatic Flatbed Die Cutter,1040×720mm Flatbed Die Cutter,7500s/H Flat Bed Die Punching Machine |
||
Product Description
Automatic Die Cutting Machine With Stripping
Product Specifications
| Automatic Grade | Semi-Automatic |
| Driven Type | Electric |
| Material | Steel |
| Power Source | Electric |
| Condition | New |
| Type | Die Cutting Machine |
| Port | TIANJIN,CHINA |
| Packaging Type | Bags, Cartons, Case |
Technical Parameters
| Model | FM-HK1050CE |
| Maximum Sheet Size | 1050×750mm |
| Minimum Sheet Size | 400×360mm |
| Maximum Cutting Size | 1040×720mm |
| Minimum Gripper Margin | 9-17mm |
| Inner Chase Size | 1140×755mm |
| Stock Range | Paper: from 80 to 2000g/m2, 0.1~2mm, corrugated board: up to 4mm |
| Die Cutting Accuracy | ≤±0.075mm |
| Max.die Cutting Force | 300T |
| Max.working Speed | 7500s/h |
| Max. feeder pile height | 1600mm(With wooden pallet) |
| Max. delivery pile height | 1400mm(With wooden pallet) |
| Machine Dimensions | 7072×4257×2349mm(L×W×H) (L: paper prepared track included, W: platform included) |
| Net Weight of Machine | 17T |
| Main motor wattage | 11kw |
| Full Load Wattage | 16.9kw |
| Air Requirement | Pressure: 0.6~0.7Mpa, Flow: ≥0.37m3/min |
